Spinal Anesthesia Kits
- • Quincke needle
- • Pencil Point needle
- • Atrau needle
Mederen spinal anesthesia kits features all range of Mederen spinal needles with a variety of procedural components in kit and set configurations.
Product Features
- Available in Quincke, Pencil Point, and Atrau needles types.
- Needle and stylet material: stainless steel.
- Pavilion material: transparent ABS plastic.
- The needle pavilion has finger rests for a comfortable grip and a standard Luer connector.
- Color coding of the needle tubing connection point to the pavilion and plastic part of the stylet according to international needle diameter labeling.
- A full range of spinal needles with or without a guide needle.
- The inner diameter of the guide needle corresponds to the external channel of the spinal needle.
- Size of aspirating cannula: 18G x 1 1/2" (1.2 x 38 mm).
- Size of aspirating cannula filter pore: 0.5 ± 0.01 μm.
- Products are sterile, pyrogen-free.
- For single use.
Available Configurations
| REF | Size | Length and Diameter, mm | Aspiration canulla | Syringe 5 ml | Film fixed | Surgical Drape | Gauze napkins | Sponges | Пuide needle | Plaster | Color code |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Quincke spinal needle | |||||||||||
| 1875Q | 18G×3" | 1,2×75 | ● | ● | ● | ● | ● | ● | ● | ||
| 1890Q | 18G×3½" | 1,2×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 1990Q | 19G×3½" | 1,0×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2075Q | 20G×3" | 0,87×75 | ● | ● | ● | ● | ● | ● | ● | ||
| 2090Q | 20G×3½" | 0,87×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2190Q | 20G×3½" | 0,82×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2240Q | 22G×1½" | 0,7×40 | ● | ● | ● | ● | ● | ● | ● | ||
| 2275Q | 22G×3" | 0,7×75 | ● | ● | ● | ● | ● | ● | ● | ||
| 2290Q | 22G×3½" | 0,7×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 22120Q | 22G×4¾" | 0,7×120 | ● | ● | ● | ● | ● | ● | ● | ||
| 2390Q | 23G×3½" | 0,63×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2490Q | 24G×3½" | 0,57×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2575Q | 25G×3" | 0,52×75 | ● | ● | ● | ● | ● | ● | ● | ||
| 2590Q | 25G×3½" | 0,52×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2590QG | 25G×3½" | 0,52×90 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 25103QG | 25G×4" | 0,52×103 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 25120QG | 25G×4¾" | 0,52×120 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 2690Q | 26G×3½" | 0,45×120 | ● | ● | ● | ● | ● | ● | ● | ||
| 2690QG | 26G×3½" | 0,45×90 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 26103QG | 26G×4" | 0,45×103 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 26120QG | 26G×4¾" | 0,45×120 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 2790Q | 27G×3½" | 0,41×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2790QG | 27G×3½" | 0,41×90 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 27103QG | 27G×4" | 0,41×103 | ● | ● | ● | ● | ● | ● | 22G×1⅓" | ● | |
| 27120QG | 27G×4¾" | 0,41×120 | ● | ● | ● | ● | ● | ● | 22G×1⅓" | ● | |
| 2990Q | 29G×3½" | 0,33×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2990QG | 29G×3½" | 0,33×90 | ● | ● | ● | ● | ● | ● | 22G×1⅓" | ● | |
| 29120QG | 29G×4¾" | 0,33×90 | ● | ● | ● | ● | ● | ● | 22G×1⅓" | ● | |
| Игла Pencil Point | |||||||||||
| 2290P | 22G×3½" | 0,7×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2290PG | 22G×3½" | 0,7×90 | ● | ● | ● | ● | ● | ● | 18G×1⅓" | ● | |
| 2390P | 23G×3½" | 0,63×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2490P | 24G×3½" | 0,57×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2590P | 25G×3½" | 0,52×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2590PG | 25G×3½" | 0,52×90 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 25103PG | 25G×4" | 0,52×103 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 25120PG | 25G×4¾" | 0,52×120 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 2690P | 26G×3½" | 0,45×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2690PG | 22G×3½" | 0,45×90 | ● | ● | ● | ● | ● | ● | 21G×1⅓ " | ● | |
| 26103PG | 26G×4" | 0,45×103 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 2790P | 27G×3½" | 0,41×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2790PG | 27G×3½" | 0,41×90 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 27103PG | 27G×4" | 0,41×103 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 27120PG | 27G×4¾" | 0,41×120 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 2990P | 29G×3½" | 0,33×90 | ● | ● | ● | ● | ● | ● | ● | ||
| 2990PG | 29G×3½" | 0,33×90 | ● | ● | ● | ● | ● | ● | 22G×1⅓" | ● | |
| Игла Atrau | |||||||||||
| 2590ATG | 25G×3½" | 0,52×90 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 25100ATG | 25G×4" | 0,52×100 | ● | ● | ● | ● | ● | ● | 20G×1⅓" | ● | |
| 2650AT | 26G×2" | 0,45×50 | ● | ● | ● | ● | ● | ● | ● | ||
| 2688ATG | 26G×3½" | 0,45×88 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
| 26100ATG | 26G×4" | 0,45×100 | ● | ● | ● | ● | ● | ● | 21G×1⅓" | ● | |
